Research on aircraft route planning optimization problem with multi-constraints and dual-targets

Abstract

As the core technology in the field of aircraft, the route planning has attracted much attention. However, due to the complexity of the structure and performance constraints of the aircraft, the route planning algorithm does not have well universality, so it cannot be used in a complex environment. In the paper, a multi-constraints and dual-targets aircraft route planning model was established for the real-time requirements of space flight, the dynamic changes of flight environment with time, the accuracy requirements of positioning errors in the safety area, and the minimum turning radius constraints. Based on the directed graph and dynamic programming ideas, the model simulation and model validation were carried out with the data of F question in the “16th Graduate Mathematical Modeling Contest”. The results showed that the optimal path length obtained in data set 1 was 124.61 km, the number of corrections was 11 times, the solution time was 2.3768 seconds, the optimal path length obtained in data set 2 was 110.00 km, and the number of corrections was 12 times. The solution time was 0.0168 seconds. Multi-constraints and dual-targets aircraft route planning model can plan the flight path of the aircraft intuitively and timely, which confirmed the effectiveness of the model.

Introduction

In the flight space, many factors need to be considered to plan a reasonable path for the aircraft according to actual needs, such as the aircraft’s own performance, structure, terrain, threat and so on, so that it can obtain an optimal path at a lower risk [1, 2], which is a NP-complete problem [3]. So far, the aircraft’s route planning algorithm is still the focus of research [4, 5]. Route planning belongs to the category of path optimization. According to the continuous and dynamic change of environment model, it is divided into global route planning and real-time local route planning. Generally, the planning space is defined as static, and the algorithm research of global route planning is carried out [6]. The main methods are route planning mathematical methods, such as dynamic planning algorithm, route planning intelligent methods [710], including article swarm optimization algorithm, simulated annealing algorithm. Route planning geometric methods, specifically shortest path algorithm. However, these algorithms do not have well universality and cannot be tracked for specific problems [11]. The route planning must be based on the premise of satisfying the constraints. Otherwise, the route planning is only the approximate ideal route under the assumed conditions, and does not have the feasibility [12].

At present, the research on multi-constraints route planning usually uses the objective function weighting to establish the evaluation index of the model, and obtain the optimal route through the algorithm. Since the aircraft usually needs to plan the flight path before performing the mission and determine a series of way-points. It is known that the flying distance of an aircraft is the shortest when it keeps a direct flight between two adjacent way-points, the distance between the selected way-points of the aircraft is relatively long. During the flight, the aircraft needs to be accurately positioned according to the positioning system to ensure that it can reach the destination and complete the flight mission. There are often positioning errors in the positioning process, including horizontal and vertical errors. The aircraft needs to locate the positioning error during the flight correction, when the aircraft reaches the correction point, it can correct the error according to the error correction type of the position. The location of the correctable flight area depends on the terrain, and there is no uniform rule. If the vertical error and the horizontal error can be corrected in time, the aircraft can fly according to the predetermined route, and the error can be corrected by several correction points to reach the destination. However, when the positioning error accumulates to a certain extent, the aircraft will not be able to fly according to the original planned route. At the same time, due to the limitation of the structure and control system, the aircraft cannot turn in time, so it cannot fly according to the original planning path. Therefore, it is of practical significance to plan reasonably the way-points with dynamic characteristics under multiple constraints.

This paper aims to minimize the path of the aircraft during flight and minimize the number of corrections in the correction area. The dual-targets model was established and the corresponding algorithm was given. Based on the idea of dynamic programming, this method embodies the advantages of multi-stage and decision-making process. Combined with the characteristics of graphical ordered search, it is essentially a path planning algorithm based on geometric principle, step generation and multi-targets constraints.

Establishment of multi-constraints and dual-targets route planning model

Problem statement

Assume that the flight area of the aircraft is as shown in Fig. 1. The starting point is point A and the destination is point B. Its route constraints are as follows:

Figure 1
figure1

Schematic diagram of the aircraft route planning area

  1. (1)

    The aircraft needs real-time positioning during space flight, and its positioning error includes vertical error and horizontal error. For every 1 m flight, the vertical error and horizontal error will increase by δ dedicated units. When reaching the ending point, the vertical error and horizontal error should be less than θ units. To simplify the problem, it is assumed that when both the vertical error and the horizontal error are less than θ units, the aircraft can still fly according to the planned path.

  2. (2)

    The aircraft needs to correct the positioning error during flight. There are some safe positions (correction points) in the flight area that can be used for error correction. When the aircraft reaches the correction point, it can correct the error according to the error correction type of the position. The location of correction of vertical and horizontal errors can be determined according to the terrain before route planning (as shown in Fig. 1, the yellow point is the correction point of horizontal error, the blue point is the correction point of vertical error, the starting point is point A, the destination is point B, and the black curve represents a route). The location of the corrected flight area depends on the terrain and has no uniform rule. If the vertical error and horizontal error can be corrected in time, the aircraft can fly according to the predetermined route, and finally arrive at the destination after error correction through several correction points.

  3. (3)

    At point A of the departure point, the vertical and horizontal errors of the aircraft are assumed be zero.

  4. (4)

    After correcting the vertical error of the aircraft at the vertical error correction point, the vertical error will be changed to zero and the horizontal error will remain unchanged.

  5. (5)

    After the aircraft performs horizontal error correction at the horizontal error correction point, its horizontal error will be changed to zero and the vertical error will remain unchanged.

  6. (6)

    Assumed that the vertical error of the aircraft is not greater than \(\alpha _{1}\) units, and the vertical error correction is corrected when the horizontal error is not greater than \(\alpha _{2}\) units.

  7. (7)

    Assumed that the vertical error of the aircraft is not greater than \(\beta _{1}\) units, and the horizontal error is corrected when the horizontal error is not greater than \(\beta _{2}\) units.

  8. (8)

    The aircraft are limited by the structure and control system during the turn and cannot complete the immediate turn (the direction of the aircraft cannot be changed abruptly), the minimum turning radius of the aircraft is assumed to be 200 m.

Through the above assumptions, the aircraft can finally arrive at the destination after error correction through several correction points.

Establishment of model

Due to the short distance between way-points relative to the earth, the earth rotation and spherical curvature are ignored. The model of the directional route map and the minimum turning radius arc are established to elaborate framework by considering the least error correction point among the route points, the shortest path length and the minimum turning radius constraints between way-points.

Establishment of dynamic directional route map

In the three-dimensional flight space, except for the end point and the start point, there are many correction points, and the correction points are converted into a directional correction point route map by establishing a directed graph, as follows:

  1. (1)

    Calculated the main direction from the starting point to the ending point;

  2. (2)

    After an error correction point, the division plane was established by using the principal direction of the point as a normal vector;

  3. (3)

    Searched all error correction points on the side of the main direction on the segmentation plane (without the ending point);

  4. (4)

    Assumed that the current horizontal and vertical errors were both zero, all reachable correction points were found according to the constraints;

  5. (5)

    Add a path from the current point to the reachable point (the direction is the current point points to the reachable point);

  6. (6)

    Perform the above operations for all points (excluding the ending point).

The establishment diagram of the directional map of the correction point of the spatial error is as follows.

It can be seen from Fig. 2(a) that the original data is randomly scattered in the space to form a spatial undirected scatter point. Figure 2(b) establishes a plane with the normal vector in the main direction from the starting point to the end point, Fig. 2(c) sets the possible path at the starting point, and Fig. 2(d) sets the path at the correction point.

Figure 2
figure2

Schematic diagram of the directed graph

Demonstration of minimum turning radius based on spatial geometry principle

In view of the constraint of the minimum turning radius \(R_{\min} = 200\mbox{ m}\), \(R \geq 200\mbox{ m}\), it is firstly analyzed and demonstrated in two-dimensional space.

As shown in Fig. 3 and Fig. 4, point \(O (0, r)\) is taken as the center of the circle, r as the radius of the circle O, and the tangent of the circle O is taken through the point, and the tangent intersects the circle O at point Q, then point \(Q (u_{q}, v_{q})\) meets the following conditions,

  1. (a)

    Point q is on circle O;

  2. (b)

    \(\overrightarrow{OQ}\) perpendicular to \(\overrightarrow{N_{i + 1}Q}\);

  3. (c)

    \(N_{i + 1}Q\) in the clockwise direction of \(\overrightarrow{ N_{ i + 1} Q}\);

Figure 3
figure3

Path analysis of the positive axis in the UV coordinate system

Figure 4
figure4

Analysis of the path of the anti-axis direction in the UV coordinate system

The coordinates of Q point are derived as follows,

$$ \textstyle\begin{cases} u_{q}^{2} + (v_{q} - r)^{2} = r^{2}, \\ u_{q}(u_{q} - uN_{i1}) + (u_{q} - r)(v_{q} - vN_{i1}) = 0, \\ (u_{q} - uN_{i1})(vN_{i1} - r) - (v_{q} - vN_{i1})uN_{i1} > 0. \end{cases} $$
(1)

The coordinates of the Q point can be obtained by solving the equations, and the coordinates of the \(Q (u_{q}, v_{q})\) point are known. The coordinates of \(N_{i+1}\) and \(N_{i}\) are known, and \(\stackrel{\frown}{{N_{i}Q}}\) can be obtained. Then you can get the new path:

$$ \stackrel{\frown}{i} = \stackrel{\frown}{N_{i}Q} + N_{i + 1}Q. $$
(2)

After repeated calculation and verification, it is found that the complex solution of the coordinates can be transformed into the solution of the route path variation ratio, which simplifies the path solving step and saves computation time. The specific derivation process is as follows:

Let, \(\angle N_{i - 1}N_{i}N_{i + 1} = \theta _{1}\), \(N_{i}N_{i + 1} = m\), \(N_{i}O = r\); Known \(N_{i}(0,0)\), \(O(0,r)\), \(N_{i + 1}(m\cos \theta _{1}, m\sin \theta _{1})\) and \(\overrightarrow{\mathit{OQ}}\) perpendicular to \(\overrightarrow{N_{i + 1}Q}\), \(\overrightarrow{\mathit{ON}_{ i}}\) perpendicular to \(\overrightarrow{ N_{ i} N_{ i + 1}}\),

From is, get

$$ \overrightarrow{N_{i + 1}Q} = \sqrt{ \vert \overrightarrow{N_{i + 1}Q} \vert ^{2} - \vert \overrightarrow{OQ} \vert ^{2}}, $$
(3)

and because of \(\alpha = \arccos [ \frac{\overrightarrow{OQ} \overrightarrow{ON_{i}}}{\overrightarrow{ \vert OQ \vert } \overrightarrow{ \vert ON_{i} \vert }} ]\), \(\stackrel{\frown}{N_{i}Q} = r\alpha \), α is the arc system, path is:

$$ \stackrel{\frown}{i} = \stackrel{\frown}{N_{i}Q} + N_{i + 1}Q = r\alpha + \sqrt{ \vert \overrightarrow{N_{i + 1}Q} \vert ^{2} - \vert \overrightarrow{OQ} \vert ^{2}}. $$
(4)

Then it can be proved that the path change ratio is:

$$ \rho = \frac{r\alpha + \sqrt{ \vert \overrightarrow{N_{i + 1}Q} \vert ^{2} - \vert \overrightarrow{OQ} \vert ^{2}} - m}{m}. $$
(5)

From Fig. 5, the path variation ratio ρ and α change as follows.

Figure 5
figure5

ρ and α changes between the diagram

As shown in Fig. 5, the variation ratio ρ gradually decreases as the α increases, and when α is at \([0, 104]\), the change is more severe and shows a downward trend. At that time, the variation ratio ρ is less than 1%, which has little impact on the value of ρ.

From Fig. 6, the variation change ratio ρ and the path length m as follows.

Figure 6
figure6

ρ and the path length m change between the diagram

As shown in Fig. 6, The variation ratio ρ gradually decreases as the length m increases. When the length m is greater than 1 km, the variation ratio is less than 1%, and when it is greater than 4.05 km, the change ratio is less than 0.1%, which has little effect on the value of variation ratio ρ.

Through the above analysis, the increase of the calculated route path changes little compared with the optimal route path without the minimum radius is limited.

Since the above inferences are all displayed in the two-dimensional plane coordinate system UV, the two-dimensional plane is now expanded into the three-dimensional space, as shown in Fig. 7.

Figure 7
figure7

Three-dimensional path analysis diagram

As shown in Fig. 7, where XYZ represents the coordinate system in three-dimensional space, where \(N_{i}N_{i + 1}\), \(\stackrel{\frown}{N_{i}O}\), and \(N_{i + 1}Q\) are the flight paths of the error correction points, the black part is the straight flight path, and the red is the arc flight path.

Establishment of multi-constraints route planning model

It is assumed that the aircraft route planning process has the shortest route length, the least number of corrections, and the minimum turning radius is the objective function, in which the sequence \(P = \{\mbox{A}, N_{1}, N_{2}, \dots N_{m}, \mbox{B}\}\) is used to represent the starting point A, the ending point B and the possible correction point.

Minimum turning arc radius model:

$$ \stackrel{\frown}{l} = R\alpha , $$
(6)

where R is the turning radius, \(\alpha = \arccos [ \frac{\overrightarrow{OQ} \overrightarrow{ON_{i}}}{\overrightarrow{ \vert OQ \vert } \overrightarrow{ \vert ON_{i} \vert }} ]\).

Total route length model:

$$ L(P) = \sum_{i = 1}^{m} \operatorname{dis}(N_{i},N_{i + 1}) + \operatorname{dis}(A,N_{1}) + \operatorname{dis}(N_{m},B) + \stackrel{\frown }{l}. $$
(7)

Where dis represents the Euclidean distance between two points in space, \(\stackrel{\frown}{l} \) represents minimum turning arc radius.

Model of correction times in route:

$$ V(P) = \sum_{i = 1}^{m} u_{i}(x). $$
(8)

Where \(u_{i}(x)\) is the number of correction times at ith route node.

$$ u_{i}(x) = \textstyle\begin{cases} 0,&\text{others}, \\ 1,&\delta h_{i}(x) < \varphi \text{ or } \delta v_{i}(x) < \varphi. \end{cases} $$
(9)

Where φ is the minimum horizontal and vertical error, \(h_{i}(x)\)and \(v_{i}(x)\) are the horizontal and vertical errors of the ith route node. Respectively, when equation \(\delta h_{i}(x) < \varphi \) and \(\delta v_{i}(x) < \varphi \) is satisfied, the correction times of the ith route node shall be recorded as 1, otherwise, the correction times shall be recorded as 0.

Multi-constraints and dual-targets path planning model:

$$\begin{aligned}& \min \bigl[ L(P),V(P) \bigr] \\& \quad \mbox{s.t. } \textstyle\begin{cases} \sum_{i = 1}^{m - 1} h_{i}(x) < \theta, \\ \sum_{i = 1}^{m - 1} v_{i}(x) < \theta, \\ \delta h_{i}(x) < \varphi, \\ \delta v_{i}(x) < \varphi, \\ r \ge 200, \\ L_{i} > L_{\min }. \end{cases}\displaystyle \end{aligned}$$
(10)

Where \(h_{i}(x)\) and \(v_{i}(x)\) are the horizontal and vertical errors of the ith route node respectively, and \(L_{\min}\) is the minimum flight distance between two adjacent correction points.

Model solution based on directed graph and dynamic programming

The introduction of the model running environment is shown in the Table 1.

Table 1 Environment introduction

Algorithm flow chart of route planning model is as follows in Fig. 8.

Figure 8
figure8

Algorithm flow chart of route planning model

The specific solution algorithm steps are as follows.

Step1: Construct a route map of the directed correction point according to the distribution of the correction points (including the start point and the end point) in the space;

Step2: Initialize the current position and record the error of the correction point;

Step3: According to the constraint condition to determine whether the path can reach the ending point, if it can, then go to step 4, if not, then perform Step 6;

Step4: Record the path, and update the directed route map to determine whether the path is the first valid path, if otherwise, execute Step 5, if yes, execute Step 9;

Step5: Judge whether the path is better than the existing path, if yes, replace the existing path with the path and execute Step 9, if otherwise, execute Step 2;

Step 6: Judge whether there is a feasible path at the current location. If there is, execute Step 7. If not, execute Step 9;

Step7: Select a path, calculate the path length and the cumulative error of the correction point according to the minimum turning radius model, and judge whether it can be corrected according to the correction type of the point. If yes, execute Step 8. If not, delete the path and return to Step 6;

Step 8: Update the current position and correct the accumulated error according to the correction type of the point, and turn to Step 3;

Step 9: Judge whether the current point is the ending point. If yes, terminate the algorithm. Otherwise, update the current position to the previous position and turn to Step 6.

Model application and evaluation

Model application

In order to verify the feasibility and effectiveness of the algorithm, a simulation experiment was carried out. The verification is performed by using two data sets, wherein the number of correction points in the data set 1 is 613, and the number of correction points in the data set 2 is 317, And each correction point contains coordinate information in space, correction point type, and mark type. The calibration points in the data set 1 are randomly selected as shown in Table 2.

Table 2 Position and correction type of 5 randomly selected points

Suppose the parameters in data set 1 are as follows: \(\alpha _{1}=25\), \(\alpha _{2} =\) 15, \(\beta _{1}=20\), \(\beta _{2}=25\), \(\theta =30\), \(\delta =0.001\). The parameters in data set 2 are as follows: \(\alpha _{1}=20\), \(\alpha _{2}=10\), \(\beta _{1}=15\), \(\beta _{2}=20\), \(\theta =20\), \(\delta =0.001\).

The solution path planning in data set 1 is shown in Fig. 9.

Figure 9
figure9

Spatial route planning representation in data set 1

As shown in Fig. 9, except for the starting point, all the correction points and ending points in the three-dimensional graph include the accumulation of vertical correction error and horizontal correction error, and the correction points are marked in yellow. The starting point and the ending point are marked in red, and the route direction was from left to right. The route length in data set 1 was calculated to be 112.43 km, and the number of correction are 8 times. Because of the arc in the route path, it is clearly marked with a red marking box in the figure, and the red arc is the increased path length. The specific route planning table is as follows,

It can be seen from the Table 3 that in addition to the starting point and the ending point, though 8 correction points, the final cumulative vertical error is 28.718 units, and the horizontal error accumulation is 19.513 units. Correction point type of 01 indicates that the vertical error correction is successful, correction point type of 11 indicates that the horizontal error correction is successful.

Table 3 Data set 1 route planning table

The solution path planning in data set 2 is shown in Fig. 10.

Figure 10
figure10

Spatial route planning representation in data set 2

The mark in the Fig. 10 is consistent with Fig. 9. The route length in data set 2 is calculated to be 110.20 km, and the number of corrections to go through is 12 times. Because of the arc in the route path, it is clearly marked with a red marking box in the figure, and the red arc is the increased path length. The specific route planning table is as follows,

It can be seen from the Table 4 that in addition to the starting point and the ending point, though 13 correction points, the final cumulative vertical error is 6.960 units, and the horizontal error accumulation is 13.514 units. Correction point type of 01 indicates that the vertical error correction is successful, correction point type of 11 indicates that the horizontal error correction is successful.

Table 4 Data set 2 route planning table

Model evaluation

(1) Discussion on the complexity of time and space

The model established by this algorithm was the nearest point search by KD-tree, which greatly improved the search speed. However, due to the different performance of different data sets in the route space, the position of the correction points was inconsistent, and the calibration point route map was also different, and the time complexity could not be directly calculated. In this paper, we used the method of average value to get the relationship between the data scale n and the calculation time. According to the density of the data correction point distribution, we randomly generated 50 groups of test models for each value of n, and the results are as follows.

It can be observed from Fig. 11 that the average running time increases as the data size n increases.

Figure 11
figure11

Quantity- time curve graph

At the same time, this algorithm used queue to save the current path points to be processed, which greatly reduces the memory consumption of the algorithm itself.

(2) Comparison of time and iteration number

Table 5 shows the length of time spent by the model in two data sets and the number of model iterators.

Table 5 Comparison of time and iterations

Through the analysis of the Table 5 and the comparison between data set 1 and data set 2, it is found that the operation results are affected by the number of correction points and correction types in data set 1, which lead to the long time spent in data set 1.

Conclusion

In the paper, the real-time requirements of the aircraft in space flight, the dynamic changes of the flight environment with time, the accuracy requirements of the positioning error in the safety area, and the minimum turning radius constraints were fully considered, and finally, the multi-constrained and dual-target aircraft route planning model was established. Through the working principle of pulley block to solve the problem of minimum turning radius restriction, the path scheme was designed and proved by space geometry transformation, which simplified the minimum turning radius restriction. It solved the problem that the positioning system could not accurately located itself due to the structural constraints of the aircraft system, and due to the limitation of structure and control system, the aircraft could not complete the real-time turning. And then, the optimal path was obtained, and the validity and superiority of the model establishment were demonstrated from multiple dimensions. Finally, two kinds of data sets were used to test the model, and the schematic diagram of flight path optimization under the two data sets was drawn, and the optimal path length and the minimum number of aircraft correction were obtained.

Experiments showed that the model established by the algorithm can not only obtain the optimal path, but also the minimum correction point. The optimal path length obtained in data set 1 is 124.61 km, the number of corrections is 11 times, and the optimal result is obtained in data set 2. The path length is 110.00 km and the number of corrections is 12 times, and the space complexity and time complexity of the algorithm show good performance.
